92-98Hz WR-10 WAVEGUIDE ISOLATOR VN-WGISO-7580-WR12

92-98GHz WR-10 WAVEGUIDE ISOLATOR

• Non‑reciprocal operation (one‑way transmission)

• Protection of expensive sources (magnetrons, amplifiers, oscillators)

• Available from 92 GHz to 98 GHz+

Working Principle of a WAVEGUIDE ISOLATOR

A WAVEGUIDE ISOLATOR is a two‑port non‑reciprocal ferrite device.
A WAVEGUIDE ISOLATOR allows microwave energy to pass with very low loss in the forward direction.
In the reverse direction, a WAVEGUIDE ISOLATOR provides very high attenuation (isolation).
A WAVEGUIDE ISOLATOR is essentially a WAVEGUIDE CIRCULATOR with one port permanently terminated internally by a WAVEGUIDE LOAD.

• Medical microwave equipment –
  A WAVEGUIDE ISOLATOR protects the generator from reflected power in diathermy or ablation systems.

• Industrial microwave heating –
  A WAVEGUIDE ISOLATOR prevents magnetron damage caused by load impedance changes during heating.

• Test laboratories and R&D –
  A WAVEGUIDE ISOLATOR is a standard component in any waveguide test bench to ensure unidirectional power flow.

In every working scenario, a WAVEGUIDE ISOLATOR acts as a protective one‑way valve for microwave energy.
